E316L-17 Stainless Steel Stick Electrodes – 14" Long, 10 lb Metal Can (Select Size From Options Above)

Low-carbon stainless steel Stick electrodes for corrosion-resistant 316L welding applications.
Washington Alloy E316L-17 electrodes produce weld deposits similar to 316 stainless steel but with a maximum 0.04% carbon. The extra-low carbon content helps provide excellent resistance to intergranular corrosion caused by carbide precipitation, making E316L-17 a strong choice where the corrosion-resistant properties of 316L stainless steel are required.

E316L-17 is designed for welding 18% Cr – 12% Ni – 2.5% Mo stainless steels and is commonly used in the fabrication of 316L, 318, and 319L stainless steel products. It provides smooth spray arc transfer, a fine slightly concave bead appearance, and self-releasing slag.

Important Ordering Information: Arc-Zone offers this electrode in 3/32" and 1/8" diameters only. Both sizes are 14" long, priced per pound, and sold in 10 lb metal cans.

Available Electrode Sizes

Select either 3/32" or 1/8" electrode diameter from the options above. Both sizes are supplied in 14" lengths.

Why Choose E316L-17?

• Low-Carbon 316L Weld Deposit: Maximum 0.04% carbon helps reduce carbide precipitation.
• Corrosion Resistance: Designed for applications where the corrosion-resistant properties of 316L stainless steel are required.
• Molybdenum-Bearing Filler: Designed for 18% Cr – 12% Ni – 2.5% Mo stainless steels.
• Smooth Arc Transfer: Provides smooth spray arc characteristics.
• Fine Bead Appearance: Produces a very fine, slightly concave weld bead.
• Self-Releasing Slag: Helps make post-weld slag removal easier.
• All-Position Capability: Can be used in all positions with proper technique and welding parameters.
• DCEP or AC: Washington Alloy provides typical SMAW procedures for either DCEP or AC operation.
• 14" Electrode Length: Both Arc-Zone size options are supplied in 14" lengths.

Common Stainless Steel Applications

E316L-17 is commonly used where the corrosion-resistant qualities of 316L stainless steel are required. Washington Alloy identifies this electrode for the fabrication of:

• 316L Stainless Steel
• 318 Stainless Steel
• 319L Stainless Steel
• Chemical Equipment
• Textile Industry Equipment
• Paper Industry Equipment
• Cellulose Processing Equipment
• Other corrosion-resistant stainless steel fabrication

Why the Low-Carbon "L" Matters

The "L" in E316L-17 identifies the electrode as a low-carbon 316 stainless classification. Washington Alloy specifies a maximum carbon content of 0.04%.

This extra-low carbon content helps reduce intergranular corrosion associated with carbide precipitation, supporting the corrosion-resistant properties required in compatible 316L stainless steel applications.

Typical E316L-17 Weld Metal Chemistry

Typical Weld Metal Properties

All-Position Welding

E316L-17 provides a wider welding current range and may be used for all-position welding. Because the slag freezes more slowly, additional care should be used when welding out of position.

How This Product Is Sold

Important: The displayed price is the price per pound, but these electrodes are sold in complete 10 lb metal cans. The total price of one can is based on 10 lbs at the listed per-pound price.

Choosing Between 3/32" & 1/8"

Frequently Asked Questions

How long are the E316L-17 electrodes?
Both the 3/32" and 1/8" electrodes are 14" long.

What is E316L-17 used for?
It is designed for welding compatible 18% Cr – 12% Ni – 2.5% Mo stainless steels where the corrosion-resistant qualities of 316L are required. Washington Alloy also identifies 316L, 318, and 319L stainless steel products as common applications.

What sizes does Arc-Zone offer?
This listing is available in 3/32" and 1/8" only. Both sizes are 14" long.

What does the "L" in E316L-17 mean?
The "L" indicates a low-carbon 316 stainless classification. The reduced carbon content helps provide resistance to intergranular corrosion caused by carbide precipitation.

What is the difference between 3/32" and 1/8"?
The 3/32" electrode operates at a lower typical amperage range of 55–75A, while the 1/8" electrode operates at approximately 80–110A in the manufacturer's flat-position procedures.

What polarity should I use?
Washington Alloy lists typical E316L-17 SMAW welding procedures using DCEP or AC.

Can E316L-17 be used in all positions?
Yes. The electrode may be used for all-position welding, but care should be used when welding out of position because of the slower-freezing slag.

How are these electrodes sold?
They are priced per pound and sold in 10 lb metal cans.

Can I purchase only one pound?
No. The minimum purchase is one complete 10 lb metal can.

What industries commonly use E316L electrodes?
Washington Alloy identifies textile, paper, cellulose, and chemical equipment industries among the common applications for E316L electrodes.
