W-250 Automation Torch (WP-22A)
250Amp Water Cooled, Machine Mounted TIG Torch Package. A versatile and easy to use automated TIG torch. Front & Back Loading Tungsten Capability.
| Specifications: | W-250 Automation Torch | ||||
|---|---|---|---|---|---|
| Amperage | 250A DCSP or 180A ACHF @ 100% Duty Cycle. | ||||
| Water-Cooled body | Barrel Style | ||||
| Electrode capacity | .040" (1.0mm) -- 1/8" (3.2mm) | ||||
| Head size | 2-Series | ||||
| Torch Length | 7" (177.8mm) | ||||
| Barrel diameter | 3/4" (19.5mm) | ||||
| Power Connection | 7/8"-14LH Male | ||||
| Gas Connection | 5/8"-18RH Male | ||||
| Water Connection | 5/8"-18LH Male | ||||
| Part # | WP-22A | WP-22A-3 | WP-22A-12 | WP-22A-25 | WP-22A-25-R |
| Cable Material | N/A | Vinyl/Plastic | Vinyl/Plastic | Vinyl/Plastic | Super Flex |
| Cable Length | N/A | 3' (0.9m) | 12.5' (3.8m) | 25' (7.6m) | 25' (7.6m) |
Specifications
View AllCloseAdditional Information
|
TIG Torch Type:
|
Water Cooled
|
|
TIG Process:
|
Machine Mounted
|
|
Torch Model:
|
Automated
|
|
Amperage Rating:
|
200 - 310 Amp
|
|
Weld Type:
|
TIG
|
|
Gun Style:
|
W-250
|
|
AMP:
|
250
|
|
Product Type:
|
Torch
|
|
Cooling:
|
Water
|
