Description
PowerArc 210STL
The PowerARC 210STL is a professional-grade inverter-based DC stick and TIG welder designed for performance and ease of use. Built on nearly a decade of customer feedback, it improves on the PowerARC 200 and 200ST models while retaining the simplicity that made them popular.
Key features include 6010/Cellulosic capability with a one-touch mode selection, VRD for enhanced safety, and an Anti-Stick function for easier rod removal. Adjustable hot start and arc force give users full control to match their welding style and environment.
For TIG, the PowerARC 210STL adds gas solenoid control, eliminating the need for a gas-valve torch. It supports lift start, live lift, optional foot pedal operation, and 2T/4T switch modes. Additional features like downslope and post flow control enhance flexibility and performance.
With its advanced functionality, competitive pricing, and robust performance, the PowerARC 210STL stands out as the top choice in its class. Compare it to similar models, and you’ll find it hard to match its value and capabilities.
Features:
- Stable, Smooth DC ARC for best Stick/TIG welds.
- IGBT Digital Inverter
- Built-in Lift TIG and Live Lift
- E6010 setting for better E6010 and cellulosic rod performance
- Digital control for precise setting and control of parameters
- Standard 35 Series DINSE style connectors
- Adjustable Arc Force Control
- Adjustable Hot Start
- VRD and Anti-Stick feature for Stick welding
- Simple, intuitive layout of controls and features
- Pedal/2T/4T Control
- Optional Pedal
Comes Complete With:
- Stick Electrode Holder with 10 ft. cable and 35 Dinse connector
- Ground Clamp with 10 ft. cable and 35 Dinse connector
- Adapter 120V/240V
- Pipeline
- Shipyards
- Fabrication Shops
- Plant/Factory Maintenance
- Shut Downs
- Farm/ Ranch
- Portable Repair
- Home Shop
Specifications:
| Part # | EVL-PA-210STL |
|---|---|
| IGBT Type |
Individual IGBT
|
|
Inverter Type
|
Digital/Micro-controlled
|
|
Output Type
|
DC Stick, DC TIG
|
|
Voltage/Phase
|
DUAL VOLTAGE 120/240 1 PHASE
|
|
Max Rated TIG Amps
|
120V: 120A 240V: 200A |
|
Max Rated Stick Amps
|
120V: 120A 240V: 200A |
|
Stick Amps @ Rated Duty Cycle
|
120V: 120A/24.8V @ 35% Duty Cycle/ 40º C 90A/23.6V @ 60% Duty Cycle/ 40º C 70A/22.8V @ 100% Duty Cycle/ 40º C 240V: 200A/28V @ 35% Duty Cycle/ 40º C 160A/26.4V @ 60% Duty Cycle/ 40º C 130A/25.2V @ 100% Duty Cycle/ 40º C |
|
Max Inrush ( I1MAX ) Amps
|
@110V: 39.2A @220V: 36.8A |
|
Maximum Rated (I1EFF ) Input Amps
|
@120V: 24A @240V: 22A |
| OCV |
Stick: 70V TIG: 70V |
|
Stick Ouput Range DC
|
120V: 10A-120A/ 20.8V-24.8V 240V: 10A-200A/ 20.8V-28V |
|
Stick Hot Start Amps
|
0-100% |
|
Stick Function
|
Adjustable Arc Force Control |
|
Stick Hot Start Type
|
Adjustable Hot Start |
|
Stick Hot Start Time
|
0-2 Seconds |
|
6010/Cellulose Capable
|
Yes |
|
Minimum Amp DC TIG Start
|
10A |
|
TIG Start Type
|
Lift TIG Live Lift |
|
Memory
|
No |
|
Down Slope Time
|
0-5 Seconds |
|
Post Flow Time
|
0-10 Seconds |
|
TIG Pulse
|
No |
|
Remote Control
|
2T/4T |
|
Foot Pedal
|
Optional |
|
Weight
|
25 lbs |
|
Dimensions (LxWxH)
|
16 in x 7 in x 13 in |
